Product Description

Boss CEB-3 Bass Chorus Pedal

A CHORUS PEDAL WITH BUILT-IN CROSSOVER

The CEB-3 Bass Chorus pedal offers a split-frequency chorus effect capable of applying warm, rich chorusing to the higher frequencies without muddying up the lows. It's the perfect chorus pedal for bassists.

Compact chorus pedal especially designed for bass guitar
Applies chorus sound to the high frequencies without altering low frequencies
Effect Level, Low Filter, Rate and Depth knobs permit precise tonal shaping
BOSS five-year warranty

Nominal Input Level: -20 dBu

Input Impedance: 1 M ohm

Nominal Output Level: -20 dBu

Output Impedance: 1 k ohm

Recommended Load Impedance: 10 k ohms or greater

Bypass: Buffered bypass

Controls:

DEPTH (Modulation depth) knob
RATE (Modulation rate) knob
LOW FILTER knob
E.LEVEL knob
Pedal switch

Indicator: CHECK indicator (Used for indication of check battery)

Connectors:

INPUT jack: 1/4-inch phone type
OUTPUT A (MONO) jack: 1/4-inch phone type
OUTPUT B jack: 1/4-inch phone type
DC IN jack

Power Supply: Alkaline battery (9 V, 6LR61)
AC adaptor (PSA series: sold separately)

Current Draw: 55 mA

Expected battery life under continuous use: Alkaline: Approx. 6 hours
*These figures will vary depending on the actual conditions of use.

Accessories: Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTES," and "Information")
Alkaline battery (9 V, 6LR61)

Options (sold separately): AC adaptor: PSA series

SIZE AND WEIGHT

Width:

73 mm
2-7/8 inches

Depth:

129 mm
5-1/8 inches

Height:

59 mm
2-3/8 inches

Weight(including battery):

420 g
15 oz
